OpenClaw 仪表板无法加载：端口、WebSockets、反向代理修复

嘿，仪表板故障排查员们——如果你正盯着一个空白页面、连接被拒或“未经授权”的错误，而 OpenClaw 的网关确实在运行，我也经历过。

上周，我在四个环境中调试了这个问题：Mac 上的本地开发、Ubuntu 上的 Docker、nginx 反向代理和一个通过 Tailscale 公开的实例。每一个都有不同的故障模式——但它们都追溯到相同的五个根本原因。

HTML 加载正常。开发工具显示 WebSocket 握手失败。网关日志没有提供有用信息。你不确定是认证、网络问题还是配置损坏。

实际问题是：代理中缺少 WebSocket 升级头，Docker NAT 将 localhost 视为外部，认证令牌未在 localStorage 中持久化，或旧的 Clawdbot/Moltbot 服务仍在运行导致端口冲突。

本指南将带你逐步诊断我在多次修复后总结的方法。从这里开始，按照检查流程操作，你要么能让仪表板正常工作，要么准确知道需要报告什么问题。

---

确认服务健康状况

Before diving into proxies and ports, verify the gateway is actually functional.

Is the Gateway Process Running?

# Check gateway status
openclaw status
# If using systemd
systemctl --user status openclaw-gateway
# Docker users
docker ps | grep openclaw-gateway

What you're looking for:

• Status: running or active
• Uptime: More than 30 seconds (not crash-looping)
• No recent restarts

If it's not running or restarting constantly, stop here and fix the gateway install issues first.

Can the WebSocket Server Respond?

Test the WebSocket endpoint directly:

# Install wscat if you don't have it
npm install -g wscat
# Test connection (replace with your actual token)
wscat -c "ws://127.0.0.1:18789/?token=YOUR_TOKEN_HERE"

Possible outcomes:

• Connected, gets challenge message → Gateway is fine, problem is browser/proxy
• Connection refused → Port/bind issue, go to next section
• Connected then immediately closes with 1008 → Auth problem

If wscat connects but the browser doesn't, the issue is either CORS, proxy config, or browser security policy.

Check What the Gateway Actually Heard

Look at recent logs:

# View last 50 log lines
openclaw logs --limit 50
# Docker
docker logs openclaw-gateway --tail 50
# Look for WebSocket handshake attempts
openclaw logs | grep -E 'ws\]|websocket|handshake'

Key patterns:

• [ws] accepted → Connection succeeded
• [ws] closed before connect ... code=1008 reason=pairing required → Auth mismatch
• [ws] closed before connect ... code=1008 reason=unauthorized: gateway token missing → Token not reaching gateway
• Origin http://... is not allowed → CORS issue

---

Port Conflicts & Bind Addresses

Problem: Gateway Binds to Wrong Interface

Symptom: Gateway runs fine via CLI, but browser can't connect to 127.0.0.1:18789.

Cause: Gateway bound to a Tailscale IP, VPN interface, or external IP instead of loopback.

This is Issue #1380 — when Tailscale is active, the gateway sometimes binds to 100.x.x.x instead of 127.0.0.1. Browser WebSocket connections to Tailscale IPs fail.

Diagnose:

# Check what interface the gateway bound to
openclaw status
# Or inspect the actual listening socket
sudo lsof -i :18789
# Look at the "NAME" column - should show 127.0.0.1:18789

Fix:

Force loopback binding in config (~/.openclaw/config.json):

{
  "gateway": {
    "bind": "loopback",
    "port": 18789
  }
}

Valid bind options:

• loopback → 127.0.0.1 only (default, safest)
• lan → 0.0.0.0 (all interfaces, requires auth)
• tailnet → Tailscale IP

After changing bind, restart:

systemctl --user restart openclaw-gateway
# or
docker compose restart openclaw-gateway

Problem: Port 18789 Already in Use

Symptom: Gateway won't start, logs show EADDRINUSE.

Cause: Old Clawdbot/Moltbot gateway still running, or another service using 18789.

Diagnose:

# Find what's using the port
sudo lsof -i :18789
# Or
sudo ss -tlnp | grep 18789

Fix Option A: Stop Conflicting Service

# Stop old Clawdbot
systemctl --user stop clawdbot-gateway
# Kill the process if needed
sudo kill -9 <PID>

Fix Option B: Change OpenClaw Port

In ~/.openclaw/config.json:

{
  "gateway": {
    "port": 18790
  }
}

Update Docker compose if using containers:

ports:
  - "127.0.0.1:18790:18790"

Then access dashboard at http://127.0.0.1:18790/.

Problem: Docker NAT Breaks Localhost Detection

Symptom: Running gateway in Docker Desktop on Windows/Mac, browser shows "pairing required" even with correct token.

Cause: Docker's NAT networking makes the gateway see connections from 172.18.0.1 instead of 127.0.0.1. Gateway treats this as an external connection requiring node pairing.

Diagnose:

Check gateway logs for:

[ws] closed before connect conn=... remote=172.18.0.1 ... code=1008 reason=pairing required

If you see remote=172.18.0.1 but you're connecting from 127.0.0.1, this is the issue.

Fix:

Add trusted proxies to your config:

{
  "gateway": {
    "trustedProxies": ["172.18.0.0/16", "172.17.0.0/16"]
  }
}

Or run gateway with --bind lan and enforce token auth:

{
  "gateway": {
    "bind": "lan",
    "auth": {
      "mode": "token",
      "token": "your-secret-token"
    }
  }
}

Better fix for Windows/Mac: Run gateway natively instead of in Docker to get real localhost connections.

---

Reverse Proxy WebSockets Checklist

If you're exposing OpenClaw through nginx, Caddy, or another reverse proxy, WebSocket support needs explicit configuration.

nginx Configuration

The dashboard uses WebSockets for real-time communication. Standard HTTP proxying breaks this.

Minimal working config:

server {
    listen 443 ssl;
    server_name openclaw.yourdomain.com;
    # SSL certs
    ssl_certificate /path/to/cert.pem;
    ssl_certificate_key /path/to/key.pem;
    location / {
        proxy_pass http://127.0.0.1:18789;
        # Critical for WebSockets
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
        # Pass through client info
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        # WebSocket timeouts
        proxy_read_timeout 86400;
        proxy_send_timeout 86400;
    }
}

Common nginx mistakes:

• Missing proxy_http_version 1.1 → WebSocket upgrade fails
• Missing Upgrade and Connection headers → Handshake rejected
• Default timeout (60s) → WebSocket closes after idle time

Detailed nginx reverse proxy guide: nginx WebSocket proxying

Caddy Configuration

Caddy handles WebSockets automatically, but you still need proper config:

openclaw.yourdomain.com {
    reverse_proxy 127.0.0.1:18789
}

That's it. Caddy auto-detects the WebSocket upgrade and adjusts timeouts.

If using subpath:

yourdomain.com {
    reverse_proxy /openclaw/* 127.0.0.1:18789
}

Then access via https://yourdomain.com/openclaw/.

Debugging Caddy WebSocket issues:

Enable verbose logging:

openclaw.yourdomain.com {
    log {
        output file /var/log/caddy/openclaw.log
        level DEBUG
    }
    reverse_proxy 127.0.0.1:18789
}

Check for websocket upgrade in logs. If missing, Caddy isn't detecting the upgrade request.

Apache Configuration

Less common but occasionally used:

<VirtualHost *:443>
    ServerName openclaw.yourdomain.com
    SSLEngine On
    SSLCertificateFile /path/to/cert.pem
    SSLCertificateKeyFile /path/to/key.pem
    # Enable proxy modules
    # a2enmod proxy proxy_http proxy_wstunnel rewrite
    ProxyPreserveHost On
    # WebSocket tunnel
    RewriteEngine On
    RewriteCond %{HTTP:Upgrade} =websocket [NC]
    RewriteRule /(.*)  ws://127.0.0.1:18789/$1 [P,L]
    # Regular HTTP proxy
    ProxyPass / http://127.0.0.1:18789/
    ProxyPassReverse / http://127.0.0.1:18789/
</VirtualHost>

Enable required modules:

sudo a2enmod proxy proxy_http proxy_wstunnel rewrite
sudo systemctl restart apache2

---

CORS / HTTPS Gotchas

Mixed Content Blocking

Symptom: Dashboard loads over HTTPS but WebSocket connection fails with mixed content error.

Cause: Browser blocks ws:// (non-secure WebSocket) when page is loaded over https://.

Fix:

Use wss:// (WebSocket Secure) behind your reverse proxy.

Your nginx/Caddy terminates SSL and forwards to http://127.0.0.1:18789, but the browser needs to connect via wss://.

Example flow:

• Browser: wss://openclaw.yourdomain.com/ → nginx with SSL
• nginx: ws://127.0.0.1:18789/ → gateway (local, no SSL needed)

The dashboard auto-detects this if you access it via HTTPS URL.

CORS Rejections

Symptom: Browser console shows CORS policy: No 'Access-Control-Allow-Origin' header.

Cause: Accessing dashboard from a different domain than the gateway expects.

Context: As of OpenClaw's security updates, the Control UI has stricter origin validation.

Fix:

If your dashboard is at https://openclaw.example.com but gateway config doesn't know about it:

{
  "gateway": {
    "cors": {
      "origins": ["https://openclaw.example.com"]
    }
  }
}

Security note: Don't use "origins": ["*"] in production. This exposes your gateway to external access vulnerabilities.

Token Not Persisting in localStorage

Symptom: Dashboard keeps asking for token every time you reload.

Cause: Browser's localStorage API blocked or cleared.

Diagnose:

Open DevTools → Application → Local Storage → http://127.0.0.1:18789

Look for key: openclaw-gateway-token

If missing after login, check:

• Browser in private/incognito mode (localStorage disabled)
• Third-party cookie blocking extensions
• Browser set to clear storage on exit

Workaround:

Use the tokenized URL every time:

openclaw dashboard

This command outputs a URL with ?token=... appended. The UI strips it after first load and saves to localStorage — but if that fails, you need the URL each time.

---

Logs to Collect Before Reporting

If none of the above fixes work, you're in edge case territory. Before opening a GitHub issue, collect these logs:

Gateway Logs

# Last 100 lines with timestamps
openclaw logs --limit 100 > gateway-logs.txt
# Docker
docker logs openclaw-gateway --tail 100 > gateway-logs.txt

Browser Console Logs

1. Open DevTools (F12)
2. Go to Console tab
3. Reproduce the connection failure
4. Right-click console → Save as... → browser-console.txt

WebSocket Frame Inspection

1. DevTools → Network tab
2. Filter: WS
3. Click the WebSocket connection
4. Check "Messages" tab for handshake details
5. Screenshot the Headers tab showing request/response

Config Sanitized

# Export config (redact tokens)
cat ~/.openclaw/config.json | sed 's/"token": ".*"/"token": "REDACTED"/g' > config-sanitized.json

Network Environment

# Check firewall rules (Linux)
sudo iptables -L -n | grep 18789
# Check what's binding to the port
sudo lsof -i :18789
# Test from external host if relevant
curl -v http://your-server-ip:18789/

---

What Actually Breaks Dashboards

在不同环境中调试后，我观察到的故障分布如下：

60% - 缺少反向代理 WebSocket 配置

• nginx 没有 Upgrade/Connection 头
• 超时设置不正确
• 缺少 proxy_http_version 1.1

20% - Docker NAT 将 localhost 视为外部

• Windows/Mac Docker Desktop
• 通过本地运行网关或添加 trustedProxies 解决

10% - 旧 Clawdbot/Moltbot 导致的端口冲突

• 安装 OpenClaw 前忘记停止旧服务
• 通过终止旧进程或更改端口解决

5% - Tailscale 绑定而非环回

• Tailscale 激活时网关绑定到 100.x.x.x
• 通过在配置中强制 bind: "loopback" 解决

5% - 认证令牌不匹配

• 配置中的令牌与 URL 中的不匹配
• 通过运行 openclaw dashboard 获取正确的令牌化链接解决

最常见的问题——反向代理 WebSocket 配置——也是最容易被忽视的，因为 HTTP 部分工作正常。你会看到 HTML 和 CSS 加载，但 WebSocket 会静默失败。

如果你在代理后运行且控制面板无法连接，这应该是你的首要检查。

在 Macaron，我们为你托管 UI——无需调试 nginx 配置，无需调整 WebSocket 超时，也无需担心 Docker NAT 的意外。如果你厌倦了在测试工作流之前进行基础设施故障排除，是否更喜欢托管的工作流 UI？创建一个 Macaron 账户。

常见问题解答

问：仪表板 HTML 加载但什么都不工作。我该从哪里开始？ 打开开发者工具 → 网络 → WS 选项卡。如果 WebSocket 握手失败，你几乎可以肯定是缺少反向代理配置中的 Upgrade 和 Connection 头。这就是 60% 的情况。如果你想先排除错误安装，我建议先对照 OpenClaw 安装指南 核对，然后再深入研究代理配置。

问：为什么即使我正确设置了令牌，我的网关仍显示“需要配对”？ 检查你的日志中是否有 remote=172.18.0.1。如果你使用 Docker Desktop（Windows 或 Mac），NAT 让网关认为你是外部连接。请在本地运行网关，或在配置中添加 trustedProxies——Docker 设置指南 有针对这种情况的具体网络配置。

问：每次刷新页面时，网关总是提示我输入令牌。 你的浏览器的localStorage没有持久化。通常是由于无痕模式、激进的隐私扩展或启用了“退出时清除存储”。使用openclaw dashboard中的令牌化URL作为变通办法。如果身份验证问题超出这个范围，OpenClaw安全检查表提供了有关令牌管理的详细信息。

问：端口18789已经被占用。是什么原因？ 十有八九是旧的Moltbot或Clawdbot网关仍在运行。lsof -i :18789可以告诉你是什么进程。结束它，或者在配置中更改OpenClaw的端口。如果你最近从Moltbot迁移，可以阅读这篇关于同时运行两者的文章——服务冲突是个常见的问题。

问：我的HTTPS仪表板无法连接到WebSocket。 混合内容——浏览器不允许在HTTPS页面上使用ws://，绝对禁止。你的代理需要处理wss://终止。如果你在VPS上遇到这个问题，VPS部署指南提供了直接可用的nginx + SSL配置。

问：Tailscale 已激活，但现在仪表板无法在本地加载。 已知问题 (#1380) — Tailscale 可能会将网关拉到 100.x.x.x 而不是 127.0.0.1。将 "bind": "loopback" 添加到您的配置中并重新启动。如果绑定行为仍然令人困惑，网关参考 清晰地分解了所有选项。
